* Main Features:
  a- Powerful measurement & calculation software packages
  b- 8-Segment TGC ABD Trackball adjustment
  c- 12 inch LCD monitor
  d- Permanent function of image store: 32 images
  e- Back-lit keyboard
  f- Scope of application: pig, dog, horse, cattle, sheep, cat, etc.
  g- 2 probe connectors
  h- Probe automatic identification
* Main Technical Specification:
  a- Scanning mode: Convex/Linear/Micro-convex/Trans-rectal;
  b- Display modes: B, B+B, B+M, M, 4B;
  c- Scanning depth: 240mm;
  d- Gray scales: 256;
  e- Function of image magnification: image zoom (real-time status under B mode), up to 5 times (area); local amplification function which can be enlarged under the real-time and froze;
  f- Image conversion: up/down, left/right, black/white;
  g- Function of puncture guide;
  h- Max dynamic range>=100db;
  i- Detecting depth>=190mm, scanning depth>=240mm;
  j- Gamma: 4 gray scale γ transform function;
  k- Variety of focus selection and multi-stage dynamic focusing with 4 transmit focus; support to launch multi-focus combination;
  l- Built-in pseudo color processor, Pal-D and VGA video output, can connect external screen monitors, color monitors, VCRs, video image printer and other equipment.
  m- Fixed characters and real-time clock and calendar display;
  n- Software reset function;
  o- Printer function: can connect laser printer and Video printer directly;
  p- Comment: Date, Name, Sex, Age, Hospital, Annotation;
  q- Zooming: *1.0, *1.2, *1.5, *2.0;
  r- Port: USB 2.0, VGA, Video connector;
* Wide application:
  a- Dog: GS, HD, CRL, BD
  b- Equine: CD, SD
  c- Cattle: CRL, HD, HL, TD
  d- Pig: HD, BD
  e- Sheep: HD, TD
  f- USB Function of image store: more than Sixteen thousand images;
  g- Power supply: AC 110V-240V, 50HZ/60HZ;
  h- Probe connector: 2;
  i- USB/VGA/ ports;
  j- Video printer connector;
* Standard configuration:
  a- 12 inches LCD main unit
  b- 2.5-7.5Mhz Multi-frequency Convex array probe;
  c- Two probe sokcets;
  d- USB,VGA, Video and printer ports;
* Options:
  a- Micro-Convex array probe;
  b- Transrectal probe;
  c- High frequency linear probe;
  d- Mitisubishi Video Printer;
  e- Inside battery
* With CE & ISO
* HS: 9018121000
* Package: 1 pc/carton, carton size:44x24.5x42cm, carton G.w./N.w.:6/5 kgs, 640 pcs/20'FCL, 1,303 pcs/40'FCL, 1,501 pcs/40'HQ.
